IEX-402-SHDSL SERIES

Managed SHDSL Ethernet extender with 1 10/100BaseT(x) port and 1 DSL port, -40 to 75 °C operating temperature

  • • Technology: Standards
  • IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) IEEE 802.3x for Flow Control IEEE 802.1p for Class of Service ITU-T G.991.2 for Single-pair high-speed digital subscriber line (G.SHDSL) transceivers: Protocols
  • SNMPv1/v2c/v3, DHCP Client, TFTP, SNTP, HTTP, Telnet, Syslog, LLDP, Modbus/TCP: MIB
  • MIB-II: Flow Control
  • IEEE 802.3x flow control, back pressure flow control: • Interface
  • DSL Port: RJ-11 (RJ45 connector) or detachable 2-contact terminal block
  • RJ45 Ports: 10/100BaseT(X) auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection
  • Console Port: RS-232 (RJ45 connector)
  • LED Indicators: PWR1, PWR2, FAULT, STATE, LINK/ACT, CO/CPE, 10/100 (TP port)
  • DIP Switches: CO/CPE, SNR/SPEED, ANNEX B/ANNEX A, STD/TURBO
  • Button: Reset button
  • • Switch Properties: MAC Table Size
  • 1K: Packet Buffer Size
  • 512K: • Physical Characteristics
  • Housing: Metal, IP30 protection
  • Dimensions: 35 x 130 x 105 mm (1.38 x 5.12 x 4.13 in)
  • Weight: 290 g (0.64 lb)
  • Installation: DIN-rail mounting, wall mounting (with optional kit)
  • Altitude: Up to 2000 m
  • Note: Contact Moxa for products guaranteed to function at higher altitudes.: • Environmental Limits
  • Operating Temperature: Standard Models: -10 to 60°C (14 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F)
  • Storage Temperature: -40 to 85°C (-40 to 185°F)
  • Ambient Relative Humidity: 5 to 95% (non-condensing)
  • • Power Requirements: Rated Voltage
  • 12/24/48 VDC (9.6 to 60 VDC), redundant dual inputs: Connection
  • 2 removable 2-contact terminal block: Overload Current Protection
  • Present: Reverse Polarity Protection
  • Safety: UL 508
  • EMC: EN 55032/24
  • EMI: CISPR 32, FCC Part 15B Class A
  • EMS: EN 61000-4-2 (ESD): Contact: 6 kV; Air: 8 KV EN 61000-4-3 (RS): 80 MHz to 1 GHz: 10 V/m EN 61000-4-4 (EFT): Power: 2 kV EN 61000-4-5 (Surge): Power: 2 kV EN 61000-4-6 (CS) 150 kHz to 80 MHz: 10 V/m EN 61000-4-8 (PFMF)
  • Shock: IEC 60068-2-27
  • Freefall: IEC 60068-2-32
  • Rail Traffic: EN 50121-4
  • Vibration: IEC 60068-2-6
  • • MTBF (mean time between failures): Time
  • 1,310,000 hrs: Standard
  • Telcordia (Bellcore), GB: • Warranty
  • Warranty Period: 5 years
  • Details: See www.moxa.com/warranty

available models

Model No. Description Quantity
IEX-402-SHDSL Managed SHDSL Ethernet extender with 1 10/100BaseT(x) port and 1 DSL port, -10 to 60 °C operating temperature
IEX-402-SHDSL-T Managed SHDSL Ethernet extender with 1 10/100BaseT(x) port and 1 DSL port, -40 to 75 °C operating temperature

optional accessories

Model No. Description Quantity
MXconfig Industrial network configuration tool
