DA-820-ETHERNET SERIES EXPANSION MODULES

2-port Gigabit Ethernet expansion module compliant with IEC62439-3 protocol for Moxa DA-820 series industrial computers
2-port Giga LAN PRP/HSR module
2-port 100 Mbps SFP fiber module (SFP module excluded)
2-port 1000 Mbps fiber card, SFP slot x 2 (SFP module excluded)

Ethernet Interface

  • 10/100/1000BaseT(X) Ports (RJ45 connector): 2
  • Magnetic Isolation Protection: 1.5 kV (built-in)

Physical Characteristics

  • Dimensions (without ears): 167 x 111 mm (6.6 x 4.38 in)
  • Weight: 212 g (0.47 lb)

Environmental Limits

  • Operating Temperature: -40 to 75°C (-40 to 167°F)
  • Storage Temperature (package included): -40 to 85°C (-40 to 185°F)

Declaration

  • Green Product: RoHS, CRoHS, WEEE

MTBF

  • Time: 1,707,210 hrs
  • Standards: Telcordia (Bellcore), GB

Warranty

  • Warranty Period: 3 years
  • Details: See www.moxa.com/warranty

Available Models

Model No. Description Quantity
DE-FX02-SFP-T 2-port 100 Mbps fiber card, SFP slot x 2, PCIe interface (SFP module excluded)
DE-GX02-SFP-T 2-port 1000 Mbps fiber card, SFP slot x 2, PCIe interface (SFP module excluded)
DA-PRP-HSR 2-port Gigabit Ethernet expansion module compliant with IEC62439-3 protocol for Moxa DA-820 series industrial computers
